Excimer lasers
CL7000 FBG
Excimer laser for the production of fiber Bragg gratings
248nm
Wavelength
100Hz
Max. repetition rate
Bragg gratings
Features
- High spatial coherence
- High stability excimer laser
- For Fiber Bragg Gratings production
Specifications
Wavelength | 248nm |
Max. repetition rate | 100Hz |
Max. pulse energy | 170mJ |
Max. average power | 17W |
Energy stability | < 0,75% |
Beam dimension(FWHM, V х H) | 4,5×16mm |
Divergence(FWHM, V х H) | < 0.3×0.3mrad |
Pulse duration(FWHM) | 20ns |
Cooling | water |
Power | 380/220 V, 50 Hz, 10 A |
Jitter | < 2ns |
PC control | RS 232 |
Spatial coherence | > 800mm |
Dimension(L х W х H) | 1430 x 380 x 760mm |
Weight | ~170kg |
